Pintail

• 2x4 Sidewalls 16” OC with 2x4 Top & Bottom Plates
• Walnut Flat Panel 36” Overhead Cabinets
• Tape, Textured & Painted 1/2” Sheetrock T/O (including closets)
• 8’ Flat Ceilings
• Steel Front & Rear Doors with Full-View Front Storm Door
• Triple Hinged 6-Panel Interior Doors
• Low E Vinyl Thermopane Tilt-in Windows
• 2x8 Floor Joists
• 3/4” Tongue & Groove OSB Floor Decking (25-year limited warranty)
• 7/16” OSB Sheathing
• Crown & Baseboard Molding Throughout
• Vinyl Floor in All Wet Areas, Hallway & Living Room
• Window Blinds & Valances
• Can Lights Above Lavs
• Porcelain Lavatories in Bathrooms T/O
• 1 Pc Fiberglass Tubs & Showers
• Metal Faucets with Scald Guard Protection
• LG Stainless Steel Kitchen Appliances:  18” Refrigerator with Icemaker, Dishwasher & Self- Cleaning Range
• Ceramic Backsplash Behind Range & Underneath Kitchen Cabinets
• Stainless Steel Kitchen Sink with Gooseneck Faucet
• Ceiling Fan in Living Room
• Whole House Water Cut-off
• 50 Gal Dual Element Water Heater in Drip Pan
• Pex Plumbing (CVPC available as an option)
• Zone III (Northern) R28 – R11 – R22 Insulation
• Outside Frost Free Hydrant Front & Rear
• Outside Electric Outlet Front & Rear
• Removable Hitch
• Vinyl Siding with 7/16” OSB Wrap
• 7/16” OSB Roof Decking
• 30 Year Dimensional Shingles

Set-up of a new single-section manufactured home includes the following:

• Concrete piers 24” diameter, 12” deep & 8” concrete
• Deliver, double block up to 48” & tie-down home
• Moisture barrier (plastic under the whole house)
• Water and sewage hooked up under the home
• 14 Seer heat pump (Heat & A/C) installed as per the print

Arrowhead Home Sales reserves the right to change specifications, standards, and set-up without incurring any obligations.

All sizes and dimensions are nominal or based on approximate manufacturer measurements.  3D Tours and photos may include retailer and/or factory installed options. Prices & specifications are subject to change based on market availability & fluctuation.
